Plasma Treatment on Titanium Surfaces for Implants

Effect of Plasma Treatment on Titanium Surface on the Tissue Surrounding Implant Material

Abstract:

Authors: Tsujita, H.; Nishizaki, H.; Miyake, A.; Takao, S. & Komasa, S.

Publication: Effect of Plasma Treatment on Titanium Surface on the Tissue Surrounding Implant Material, International Journal of Molecular Sciences, 2021, 22.

First published: https://www.mdpi.com/1422-0067/22/13/6931

The effect of cold atmospheric plasma on a titanium surface was investigated via SEM, XPS, contact angle, cell morphology and ROS. Furthermore, the implants were implanted in a rat femur for in vivo analysis. After eight weeks the hard tissue integration was investigated via CT analysis and histological analysis.

Both, the in vitro and the in vivo analysis show an altered titanium surface, resulting in a better wettability and thus an increased amount of new bone formation in the tissue surrounding the implant.

Overview on the different analyses
Fig. 1. The study design is shown. Experiments can be divided into two areas. One is to confirm how the atmospheric pressure plasma treatment on titaniumsurface affects thematerial surface. The other is an in vivo analysis using rat femur. Eight weeks after implantation the rat was euthanized and the femur was removed together with the implant and CT analysis and histological analysis were performed.

Total recap:

The effect of surface modification of titanium implants on bone formation is the object of several investigations. Especially cold atmospheric plasma treatment shows promising results. While most investigations focus on in vitro investigations, this work from Tsujita et al. links the surface characterization with investigations of hard tissue integration in vivo.

Titan implants were treated with cold atmospheric plasma generated by the piezobrush® PZ2 for 30 seconds at a distance of 10 mm. The process gas was generated by the device from the ambient air.

The surface properties were investigated by SEM, XPS and contact angle analysis. The SEM analysis revealed that the plasma treatment did not change the surface structure. The effect of the plasma is based on surface manipulation in atomic scale, which results in a reduced carbon load on the surface, as shown with XPS. The water contact angle was before the treatment 32°, after the plasma treatment the implant was superhydrophilic.

SEM image of plasma treated and untreated titanium screws
Fig. 2. SEM image of plasma treated (a,c) and untreated (b,d) titanium screws.

The tissue integration of implants is strongly dependent on the cell adhesion behavior. Therefore, the adhesion of RBMC cells was investigated. While the cells on the untreated titanium (Fig. 3 b,d) have an oval shape, the cells on the treated titanium (Fig. 3 a,c) are enlarged and filamentous pseudopodia were acquired.

SEM images of RBMC cells on titanium plates shows the effect of plasma treatment on titanium surface
Fig. 3. SEM images of RBMC cells on titanium plates. Left: plasma-treated, right: untreated.

Additional to the in vitro experiments, plasma-treated and untreated titanium implants were implanted in the rat femur. After eight weeks of healing, the implant was further investigated. In figure 4, you see a three-dimensional computer tomography picture of the implant. It is clearly obvious that the amount of new bone formation is for the treated implant higher (Fig. 4 a) than for the untreated implant (Fig. 4 b).

The three-dimensional computer tomography shows the effect of plasma treatment on titanium surface on the tissue around implants
Fig. 4. Three-dimensional computer tomography of the plasma-treated (a) and untreated (b) implant eight weeks after implantation.

From quantitative histomorphometric analysis (fig. 5), both, the bone area ratio (BA), and the bone-to-implant contact (BIC) could be determined. Both values are strongly enhanced for the plasma treated implants. In combination with the histopathological image of the bone tissue around the implant and the fluorescent labelled dynamic tissue morphometry, a early enhanced osseointegration and formation of hard tissue could be confirmed.

Quantitative histomorphometric analysis of bone area ratio and bone-to-implant contact
Fig. 5. Quantitative histomorphometric analysis of bone area ratio (BA) and bone-to-implant contact (BIC).

Early osseointegration is important to achieve initial stability after implant placement. In the investigation, control and experimental groups included untreated screws and those irradiated with atmospheric-pressure plasma using the piezobrush, respectively. The femurs of rats were used for in vivo experiments. Micro-CT analysis showed that more new bone was formed in the test group than in the control group. Similar results were shown in histological analysis. Thus, titanium screw, treated with atmospheric-pressure plasma, could induce high hard tissue differentiation even at the in vivo level.

Read the whole report here.
